Détails sur le produit:
|
| Type de cellule: | Monocristallin 182mm | Nombre de cellules: | 108 (6x18) Demi-coupe |
|---|---|---|---|
| Dimensions du module: | 1722x1134x30mm | Poids: | 21,5 kg |
| Tension nominale: | 48V DC | Vmp chez STC: | 37.5V |
| COV chez STC: | 44.6V | Verre avant: | Verre AR trempé de 3,2 mm |
| Cadre: | Aluminium anodisé argent | Boîte à jonction: | IP67, 3 diodes de dérivation |
| Mettre en évidence: | 48V monocrystalline solar panel 400W,MPPT optimized solar panel,DC solar panel for battery charging |
||
The KUOMAN KS-400M-48V is specifically voltage-optimized for 48V battery storage systems. With a carefully tuned Vmp of 37.5V, this 400W monocrystalline panel pairs seamlessly with MPPT charge controllers to efficiently charge 48V battery banks including lithium-ion, lead-acid, and LiFePO4 chemistries without the efficiency losses of DC-DC voltage conversion stages.
| Parameter | Specification |
|---|---|
| Maximum Power (Pmax) | 400W |
| Voltage at Pmax (Vmp) | 37.5V |
| Open Circuit Voltage (Voc) | 44.6V |
| Current at Pmax (Imp) | 10.7A |
| Module Efficiency | 21.0% |
| Nominal System Voltage | 48V DC |
Contact KUOMAN for 48V solar panel solutions optimized for your battery storage project.
